Product Details
Place of Origin: Jiangsu, China
Brand Name: TONGLINT
Certification: TS16949
Model Number: S400
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Packaging Details: Carton
Delivery Time: 5-10 working days
Payment Terms: T/T, Western Union, PayPal
Supply Ability: 5000 sets/ Month
Product: |
Turbo Turbocharger |
Model: |
S400 |
Part Number: |
316699 |
OEM Number: |
0060966699, 0070966499, 0070967899, 0070964699, A0060966699, A0070966499, A0070967899, A0070964699, 0070964799, A0070964799, 0080965999,A0080965999, 417495-A |
Material: |
K418 Turbine Wheel; C355 Compressor Wheel |
Engine: |
OM501LA, OM501LA Euro-3, OM501LA |
Product: |
Turbo Turbocharger |
Model: |
S400 |
Part Number: |
316699 |
OEM Number: |
0060966699, 0070966499, 0070967899, 0070964699, A0060966699, A0070966499, A0070967899, A0070964699, 0070964799, A0070964799, 0080965999,A0080965999, 417495-A |
Material: |
K418 Turbine Wheel; C355 Compressor Wheel |
Engine: |
OM501LA, OM501LA Euro-3, OM501LA |
| Part Number | 316699 |
| Previous Version | 53319887127, 317405 |
| OE number | 0060966699, 0070966499, 0070967899, 0070964699, A0060966699, A0070966499, A0070967899, A0070964699, 0070964799, A0070964799, 0080965999,A0080965999, 417495-A |
| Year | 1997-11 |
| Description | Actros Truck Euro 3 |
| Manufacturer Part Number | 316429, 317762, 318052, 317405, 53319707127 |
| CHRA | 316700 |
| Turbo Model | S400 |
| Engine | OM501LA, OM501LA Euro-3, OM501LA |
| Displacement | 11.97L, 11950 ccm, V6 Cylinders |
| KW | 315/428 HP |
| Fuel | Diesel |
| RPM | 1800 |
| Angle α (compressor housing) | 54° |
| Angle β (turbine housing) | 0° |
| Bearing Housing | 317028/315498 |
| Turbine Wheel | 315273 |
| Comp. Wheel | 169956 |
| Back plate | 316010 |
| Heat shield Number | 315964 |
| Repair Kit | 318396/318397 |
| Turbine Housing | 316431 |
| Compressor Cover | 316424 |
| Gasket (turbine inlet) | 210648 |
| Gasket (turbine outlet) | 210239 |
| Gasket (oil outlet) | 210060 (2475013) |
| NOTE | Also for 230, 260 and 290 kW |
| Brand | Tonglint |
