H20 Auto Quadrotor Drone with 3-Blade Propeller for Agricultural Spraying

Product Details

Place of Origin: China

Brand Name: TONGLINT

Model Number: H20

Payment & Shipping Terms

Minimum Order Quantity: 1 pc

Packaging Details: Neutral Packing

Delivery Time: 30 days

Payment Terms: T/T

Get Best Price
Highlight:
Fuselage Weight:
23.5 KG
Propeller Dimension:
840mm
Numbers Of Propellers:
4 Groups (12)
Operating Temperature Range:
-5~40℃
Fuselage Dimension:
1250*1250*650mm
Folding Dimension:
691*670*650mm
Battery Capacity:
51.8V, 14s, 20000mAh, Lithium Battery
Medicine Tank Capacity:
22L
Numbers Of Nozzles:
4 Pcs
Operation Flight Speed:
1-10m/s (Adjustablel)
Spraying Width:
6-7m
Spraying Flow Rate:
2.3-7.4L/min (Adjustablel)
Diameter Of Droplet:
120-200μm
Dosage:
12~90L/ha (Adjustable)
Numbers Of Pumps:
2 Pcs
Flight Time With Full Load:
10.3min
Flight Time With No Load:
24.6min
Spraying Height Above The Crop Canopy:
2m
Error Of Flowmeter Accuracy:
≤3%
Fuselage Weight:
23.5 KG
Propeller Dimension:
840mm
Numbers Of Propellers:
4 Groups (12)
Operating Temperature Range:
-5~40℃
Fuselage Dimension:
1250*1250*650mm
Folding Dimension:
691*670*650mm
Battery Capacity:
51.8V, 14s, 20000mAh, Lithium Battery
Medicine Tank Capacity:
22L
Numbers Of Nozzles:
4 Pcs
Operation Flight Speed:
1-10m/s (Adjustablel)
Spraying Width:
6-7m
Spraying Flow Rate:
2.3-7.4L/min (Adjustablel)
Diameter Of Droplet:
120-200μm
Dosage:
12~90L/ha (Adjustable)
Numbers Of Pumps:
2 Pcs
Flight Time With Full Load:
10.3min
Flight Time With No Load:
24.6min
Spraying Height Above The Crop Canopy:
2m
Error Of Flowmeter Accuracy:
≤3%
H20 Auto Quadrotor Drone with 3-Blade Propeller for Agricultural Spraying

H20 Auto Quadrotor Drone with 3-Blade Propeller for Agricultural Spraying 0 H20 Auto Quadrotor Drone with 3-Blade Propeller for Agricultural Spraying 1

3-BLADE PROPELLER DESIGN

  • Extend blade service life
  • Improve the safety of the whole machine and the reliability of components.



HIGH INTELLIGENT CONTROL

  • One-key takeoff and landing
  • One-control multi-aircraft
  • Fully autonomous planning operation
  • Imitation flight
  • Breakpoint endurance
  • Flight data sharing
  • Real-time control of drug dosage
  • Real-time and accurate battery data return
  • Support fo spot checking / autonomous obstacle avoidance



AVIATION ALUMINIUM + CARBON FIBER MATERIAL

  • The key components are all made of aviation aluminium and carbon fiber materials. It guarantees corrosion resistance, aging resistance and better flight resistance.



CORE COMPONENT WITH IP56 PROTECTION DESIGN

  • The whole machine can be directly rinsed with water, making cleaning more convenient, time-saving and efficient.



ENVELOPING-FOLDING DESIGN

  • 72% reduction in volum
  • No need to buy a special vehicle
  • Save the cost of transportation



FPV HIGH-DEFINITION CAMERA

  • Front FPV HD camera, and 15000m effective HD image transmission
  • Real-time monitoring of flight environment
  • Convenient and efficient operation of mapping



RTK-CENTIMETER-LEVEL POSITIONING

  • Dual redundancy system of GNSS and RTK, allowing more accurate route
  • Dual antenna with directional anti magnetic interference technology make flight safer.



PRECISE SPPAYING

  • The nozzle is designed to tilt upward at 15 degrees, making the distribution of fog droplets more uniform.
  • Dual pump control, flow up to 7.4L/min
  • High precision flowmeter
  • Precise control of pesticide consumption
