Product Details
Place of Origin: Jiangsu ,China
Brand Name: TONGLINT
Certification: TS16949 / SGS
Model Number: Various
Payment & Shipping Terms
Minimum Order Quantity: 1
Delivery Time: 1-5 working days
Payment Terms: Western Union, T/T
Supply Ability: 10000 per month
Description: |
Shaft Nut |
Packaging Details: |
Neutral Packing |
Delivery Time: |
1-5 Working Days |
Minimum Order Quantity: |
10 Pcs |
Description: |
Shaft Nut |
Packaging Details: |
Neutral Packing |
Delivery Time: |
1-5 Working Days |
Minimum Order Quantity: |
10 Pcs |
| Code | Model | Thread | Thread Hand | Type |
| GT Series | ||||
| T-SN-1001 | GT12 | M4*0.7 | LH | HEX FLANGE |
| T-SN-1002 | GT15/GT17 GT18/GT20 GT22/GT25 |
M5*0.8 | LH | TORX |
| T-SN-1003 | GT35 | 1/4-28UNF | LH | TORX |
| T-SN-1004 | GT37/GT40 GT37VAS |
M7*1.0 | LH | TORX FLANGE |
| T-SN-1005 | GT42/GT45 | M8x1.25-LH | ||
| T-SN-1006 | T2/T250 TB25/TB28 |
M6*1.0 | LH | TORX |
| T-SN-1007 | TA31/TB31 TB34/TBP4 TO4B/TO4E |
1/4-28UNF | LH | TORX FLANGE |
| T-SN-1008 | TA45/TA51 | 5/16-24UNF | RH | TORX |
| T-SN-1009 | TV61 TV81 |
3/8-24 | RH | HEX |
| T-SN-1010 | T04S | 5/16-24 | RH | TORX |
| T-SN-1011 | T04S | 5/16-24 | LH | TORX |
| T-SN-1012 | GT28 GT28R |
M6*1.0 | LH | |
| T-SN-1013 | BGT14V | M4x0.5 | LH | |
| T-SN-1014 | GTP38 | 1/4-28UNF | RH | |
| T-SN-1015 | ST50/VT50 T46 |
M12*1.25 | RH | HEX |
| T-SN-5006 | TV75 | 3/8-24UNF | RH | HEX |
| H Series | ||||
| T-SN-2001 | H1C/H1E HX30 HX35/HX40 |
M7*1.0 | LH | TORX |
| T-SN-2002 | H2D/H2C HX50/HX55 |
M8*1.25 | LH | HEX |
| T-SN-2003 | H2D/H2C HX50/HX55 |
M8*1.25 | LH | TORX FLANGE |
| T-SN-2004 | HT3B/HT60 HX60 |
M10*1.25 | RH | HEX |
| T-SN-2005 | HC5A/HX80 | M11*1.0 | LH | HEX |
| T-SN-2006 | HE551/HE561 | M8*1.25 | LH | TORX |
| T-SN-5001 | HT3B HT60 |
7/16-20UNF | RH | HEX |
| RH Series | ||||
| T-SN-3001 | RHF3 | M4*0.5 | LH | HEX |
| T-SN-3002 | J52/RHE4 RHB5 |
M5*0.5 | LH | HEX |
| T-SN-3003 | RHF4 RHF5 |
M5*0.5 | LH | HEX |
| T-SN-3004 | RHC6/RHE6 RHF55 |
M6x0.75 | LH | HEX |
| T-SN-3005 | RHG6 RHC7 |
M7*0.75 | LH | HEX |
| T-SN-3006 | RHV4H | M5*0.5 | LH | TORX |
| T-SN-6001 | RHB3 | M4*0.7 | LH | HEX FLANGE |
| T-SN-7004 | VF40 | M5*0.5 | LH | TORX |
| K Series | ||||
| T-SN-4001 | K03 K04 |
M4.5*0.5 | LH | HEX |
| T-SN-4002 | K14 K16 |
M5*0.8 | LH | HEX |
| T-SN-4003 | K26 5003-550-5281 |
M8*1.25 | RH | HEX |
| T-SN-4004 | K27 | M7*1.0 | LH | HEX |
| T-SN-4005 | K31/K33 | M8*1.0 | LH | HEX |
| T-SN-4006 | BV35/KP35 BV39/KP39 |
M4*0.5 | LH | HEX |
| T-SN-4007 | K24 | M5*0.5 | LH | HEX |
| T-SN-5001 | K29 | 7/16-20UNF | RH | HEX |
| T-SN-5004 | K28 | M7*1.0 | LH | HEX |
| HX Series | ||||
| T-SN-1008 | 3LM | 5/16-24UNF | RH | TORX |
| T-SN-5001 | 4LE/4LG | 7/16-20UNF | RH | HEX |
| T-SN-5002 | S1B S100 |
M5*0.8 | LH | HEX |
| T-SN-5003 | S2A | 1/4-28UNF | LH | HEX |
| T-SN-5004 | S2B/S2E S200 |
M7*1.0 | LH | HEX |
| T-SN-5005 | 3LD S3A/S3B S300/S310 |
M8*1.25 | LH | HEX |
| T-SN-5006 | S4D | 3/8-24UNF | RH | HEX |
| T-SN-5007 | S400/S410 | M10*1.5 | LH | HEX |
| T-SN-5005 | S500 | M8*1.25 | LH | HEX |
| T-SN-5002 | B1 | M5*0.8 | LH | HEX |
| T-SN-5004 | B2 | M7*1.0 | LH | HEX |
| TD Series | ||||
| T-SN-6001 | TD025/TF025 | M4*0.7 | LH | HEX FLANGE |
| T-SN-6002 | TD03 TF035/TD04 |
M5*0.8 | LH | HEX FLANGE |
| T-SN-6003 | TD05 TD06 |
1/4-28UNF | LH | HEX FLANGE |
| T-SN-6004 | TD07S | M7*1.0 | LH | HEX |
| T-SN-6005 | TD07 TD08 |
M8*1.25 | LH | HEX |
| CT Series | ||||
| T-SN-7001 | 1KD/2KD CT16/CT16V CT9/CT12B |
M5*0.5 | LH | TORX |
| T-SN-7002 | CT12 | M5.5*0.5 | LH | TORX |
| T-SN-7003 | CT20 CT26 |
M6*1.0-6H | LH | TORX |
| T-SN-7004 | CT9 genuine | M5*0.5 (18 tooth) |
LH | TORX |
| Other Series | ||||
| T-SN-8001 | HT12 | M5*0.8 | LH | HEX |
| T-SN-8002 | B03 | M5*0.8 | RH | HEX FLANGE |
| T-SN-8003 | B9 IS38 |
M5*0.5 | RH | TORX |
| T-SN-8004 | KTR130 | M14x1.5 | LH | HEX |
| T-SN-8005 | 5/16-24 | LH | HEX | |
| T-SN-8006 | 5/16-24 | RH |
HEX |
|
